WFS Series Waste Incinerator
.png)
1. Description：
BOYN WFS Series Waste Incinerator is a kind of machine that was developed on the basis of Japanese technology, absorbs advantages of similar equipment both domestic and abroad. It features unique and advanced merits with compact size, high burning effect, reasonable burning technology, high degree of non-harm etc. It is an ideal choice for waste treatment of hospitals, hotels, industrial, waste recycling and other various areas.
2. Advantage
1) Long lifetime
2) Totally enclosed operation
3) Suitable for treating infectious waste
4) Avoid secondary pollution
5) Simple operation
3. Main features
1) Both gas-motivated and oil-motivated are all can be preferred according to customers' needs.
2) Gasified incineration is used for burning syringe, paper waste, bandage, absorbent cotton and other medical wastes, industrial waste, animal body and domestic waste.
3) Daily waste can be burned once by gasified incineration.
4) Gasified incineration, mixed incineration and burnout treatment ensures low emission standard of dust (lower than International standard).
4. Technical Parameters:
| Model |
WFS-50 |
| Loading capacity maximum |
50kgs X 6=300kgs/day , |
| Burning Capacity |
50kgs/h , (3-6 times/day) |
| Ash residue |
Less than 2% |
| Gas/oil retention time |
More than 2sec |
| Waste inlet size |
620*800mm or large |
| Volume of incinerator |
1st burning chamber: 0.5m3
2nd burning chamber: 0.3m3
Mixed combustion chamber: 0.04m3 |
| 1st burning temperature |
600℃~900℃ |
| 2nd burning temperature |
850℃~1300℃ |
| Main combustor power |
0.11KW , Oil consumption: 4-10kg/h |
| Re-combustor power |
0.11KW , Oil consumption: 4-10kg/h |
| Combustor brand |
Career |
| Air blower |
0.37KW |
| Voltage |
380V/220V, 60/50Hz |
| Material |
Q235 Carbon steel with anti-corrosion paint for main body. , fire proof bricks inside the burner. |
| Chimney |
Ø280mm * 6m with rain proof cap |
| Shape dimension |
Length: 1800mm
Width :1150mm
Machine height : 3000mm
Chimney high: 6000mm |
| Weight |
About 4800kgs |
1.A complete system with main body, two burners, one air blow, temperature control, oil tank, electrical control box, Air pipelines, Chimney, Ash rake etc.
2.With 3D video guide for installation, Electricity customized, Fuel customized.
|
