Specification

RO water system

DI water system

Ultrapure water system

Model

RO 1600-E

RO DI1600

RO DI1600-E

UP 1600

UP 1600-E

Flow procedure

PF+AC+RO+AC

PF+AC+RO+AC+DI

PF+AC+RO+AC+DI

Feed water requirements

Tap water: TDS<200ppm, 5-45°C, 1.0-4.0Kgf/cm²

Purification system

Pretreatment unit

20" spun fiber filter ×2+20" granular active carbon filter ×2+20" active carbon block filter ×2

RO unit

400GPD RO membrane×4

Subsequent unit

10' granular activated carbon filter×2

10'' granular activated carbon filter×2+25L mixed bed resin cartridge ×1

10'' granular activated carbon filter×2+25L ultrapure polishing resin cartridge ×1

Pure water quality

·         RO water system- TDS(Total dissolved solid) of RO water(ppm)<TDS of inlet water×5%

·         DI water system- Resistivity of DI water≥10M×.cm

·         Ultrapure water system --Resistivity of ultrapure water:18.2M×.cm

Output(25°C)

250 liters/hour*

Outlet

RO water

RO water, DI water

RO water, UP water

Optional

·         185 and 254nm UV cartridge, to achieve effective sterilization and reduce TOC index.

·         5000 Doulton ultra-filtration cartridge , to eliminate endotoxin.

·         0.2µm PES terminal filter, to assure the quality absolutely axenic.

Innovation

·         All in one design

·         2 sets 800 GPD pure water system, independent operation. if one was broken, the other also run.

·         The voltage is only DC24V, lower than safe voltage(DC36V)

·         Working pressure of RO membrane<70PSI(4.9kgf/cm²),assure safety.

·         Floor space is only 0.5m2, save more room for laboratory

Electric requirements

AC110-220V,50/60Hz / 500W

Dimension and weight

Length×Width×Height:76×55×121cm / 85Kg

Standard configuration

Main body(including:1 set cartridge)+ accessory box
