Specification

Standard

Eliminating endotoxin

Low TOC

Comprehensive

Model

UP 300/400/600/800

UP 300/400/600/800UF

UP 300/400/600/800UV

UP 300/400/600/800UVF

Flow procedure

PF+AC+RO+AC+DI+TF

PF+AC+RO+AC+DI+UF+TF

PF+AC+RO+UV+AC+DI+TF

PF+AC+RO+UV+AC+DI+UF+TF

Application

Microanalysis Environmental analysis

Molecular biology

Micro organic analysis

Molecular biology

AA,ICP,IC

PCR, gene research

Environmental analysis

Micro organic analysis

Buffer disposing

Pharmacy research

HPLC,TOC

Environmental analysis

Pharmacy research

Medicine examining,

VOC,GC/MS

Pharmacy research

Medicine examining,

Cell cultivating

Pharmacy research

Medicine examining

IVF etc.

Medicine examining,

Cell cultivating, IVF etc.

Feed water requirement

Tap water: TDS<200ppm,5-45°C,1.0-4.0Kgf/cm²

(if inlet TDS>200ppm,extra pretreatment is recommended)

Purification system

Pretreatment unit

20" spun fiber filter×1+20" granular active carbon filter×1+20" active carbon block filter×1

RO unit

300 series:300 GPD RO membrane×1, 400 series:400 GPD RO membrane×1

600 series:300 GPD RO membrane×2, 800 series:400 GPD RO membrane×2

Subsequent unit

·         10'' granular active carbon filter×1+

12L ultrapure polishing resin cartridge×1+ultrapure polishing resin cartridge×2+0.2µm terminal filer×1

·         UV model:+Double wavelength(185&254)nm UV cartridge×1

·         UF model:+5000 Doulton UF cartridge×1

·         UVF model:+Double wavelength(185&254)nm UV cartridge×1+5000 Doulton UF cartridge×1

Ultrapure water quality

Resistivity:18.2 MΩ.cm, Heavy metal<0.1ppb, TOC<10ppb(UV model), Endotoxin<0.001Eu/ml(UF model), particle(>0.22µm)<1/ml, Bacteria <1cfu/ml

RO water quality

TDS(Total dissolved solid) of RO water(ppm)<TDS of inlet water×5%

Output(25°C)

300 series:45 liters/hour*, 400 series:63 liters/hour*

600 series:94 liters/hour*, 800 series:125 liters/hour*

Pure water outlet

RO water, ultrapure water

Features and functions

·         Super-large LCD display, display the system running state and various parameters intuitively.

·         Automatic microcomputer controlling system, multi-menu operating, animation mode display.

·         Fault is detected automatically, automatic diagnosis.

·         Water quality over standard alarm, no water alarm, consumables end alarm function.

·         Consumables residual life shows, inform the user to replace consumables timely.

·         3-way on-line sensor, detecting the quality of feed water, RO water and ultrapure water's quality timely.

·         Unique design of consumables, easy for replacement.

·         High-strength stainless steel shell, beautiful appearance.

·         Pipeline with NSF authorization to assure high quality ultrapure water

·         New easy-inserting adaptor to make convenience of cartridge maintaining and replacing.

·         Different tanks to meet every needs and assure ample water-supply.

·         RO membrane, manufactured by DOW, to assure RO membrane's long time and high quality of pure water.

·         Ultrapure polishing resin cartridge with DOW's polishing resin, to assure the top-level water quality of ultrapure water.

·         Double wavelength(185&254 nm)UV cartridge, to achieve effective sterilization and reduce TOC index.

·         5000 Doulton ultra-filtration cartridge, Manufactured in Germany, to eliminate endotoxin. Suitable for Cell cultivating and IVF.

·         0.2µm PES terminal filter, to assure the quality absolutely axenic.

Electric requirements

AC110-220V,50/60Hz ,300/400 series-120W, 600/800-240W

Dimension and weight

Length×Width×Height:64×54×11 1cm / 70kg

Standard configuration

Main body(including:1 set cartridge)+2× interior 4 gallon tank+ accessory box
