Model

RO DI300

RO DI400

RO DI600

RO DI800

Flow procedure

PF+AC+RO+AC+DI+TF

Application

·         ●ware washing ●Agricultural expe ●General biological expe ●Aquatic products feeding ●Inlet water for Ultra pure water machine ●Inlet water for sterilizer/T&H chamber ●Buffer disposing ●Aseptic drinking water ●Physical and chemical analysis ●Fine chemistry industry ●Inlet water for Ultra pure water machine ●GC/HPLC ●Pharmacy research ●Medicine examining

Feed water requirements

Tap water: TDS<200ppm,5-45°C,1.0-4.0Kgf/cm²

(if inlet TDS>200ppm,extra pretreatment is recommended)

Purification system

Pretreatment unit

20" spun fiber filter×1+20" granular active carbon filter×1+20" active carbon block filter×1

RO unit

300 GPD RO membrane×1

400 GPD RO membrane×1

300 GPD RO membrane×2

400 GPD RO membrane×2

Subsequent unit

10'' granular active carbon filter×1+12L mixed bed resin cartridge×1+0.2µm terminal filer×1

Deionized water quality

Resistivity

>10MΩ.cm

Conductivity

<0.1µs/cm

Heavy metal

<0.1ppb

Particle(>0.22µm)

<1 CFU/ml

Bacteria

<1/ml

RO water quality

TDS(Total dissolved solid) of RO water(ppm)<TDS of inlet water×5%

Output(25°C)

45 liters/hour*

63 liters/hour*

94 liters/hour*

125 liters/hour*

Pure water outlet

2:RO water, deionized water

Features and functions

·         Super-large LCD display, display the system running state and various parameters intuitively.

·         Automatic microcomputer controlling system, multi-menu operating, animation mode display.

·         Fault is detected automatically, automatic diagnosis.

·         Water quality over standard alarm, no water alarm, consumables end alarm function.

·         Consumables residual life shows, inform the user to replace consumables timely.

·         3-way on-line sensor, detecting the quality of feed water, RO water and DI water's quality timely.

·         Unique design of consumables, easy for replacement.

·         High-strength stainless steel shell, beautiful appearance.

·         Pipeline with NSF authorization to assure high quality ultrapure water

·         New easy-inserting adaptor to make convenience of cartridge maintaining and replacing.

·         Different tanks to meet every needs and assure ample water-supply.

·         RO membrane, manufactured by DOW or CSM, to assure RO membrane's long time and high quality of pure water.

·         Ultra pure polishing resin cartridge with DOW's polishing resin, to assure the top-level water quality of ultrapure water.

·         0.2µm PES terminal filter, to assure the quality absolutely axenic.

Electric requirements

AC110-220V,50/60Hz ,120W

AC110-220V,50/60Hz ,240W

Dimension and weight

Length×Width×Height:64×54×11 1cm / 70kg

Standard configuration

Main body(including:1 set cartridge)+2×interior 4 gallon tank+ accessory box
