Specification

Standard

Eliminating endotoxin

Low TOC

Comprehensive

Model

Research

Research UF

Research UV

Research UVF

Flow procedure

AC+DI+TF

AC+DI+UF+TF

AC+UV+DI+TF

AC+UV+DI+UF+TF

Application

Microanalysis Environmental analysis

Molecular biology

Micro organic analysis

Molecular biology

AA,ICP,IC

PCR, gene research

Environmental analysis

Micro organic analysis

Buffer disposing

Pharmacy research

HPLC,TOC

Environmental analysis

Pharmacy research

Medicine examining,

VOC,GC/MS

Pharmacy research

Medicine examining,

Cell cultivating

Pharmacy research

Medicine examining

IVF etc.

Medicine examining,

Cell cultivating, IVF etc.

Feed water requirements

RO water, distilled water, deionized water.5-45°C,1atm*

Purification system

Post active carbon filter×1

+Mixed bed resin cartridge×1+Ultrapure polishing resin cartridge× 4+(0.45+0.2)µm terminal filer×1

UV model:+Double wavelength(185&254)nm UV cartridge×1

UF model:+5000 Doulton UF cartridge×1

UVF model:+Double wavelength(185&254)nm UV cartridge×1+5000 Doulton UF cartridge×1

Pure water quality

Resistivity

18.2MΩ.cm@25°C

Heavy metal

<0.1ppb

TOC

<10ppb

<5 ppb

Endotoxin

-

<0.001EU/ml

-

<0.001EU/ml

Particle(>0.22µm)

<1/ml

Bacteria

<1cfu/ml

Output

1.5-1.8 liters/min (with pressure tank) (Less output with UF/UV cartridge)

Pure water outlet

Deionized water, ultrapure water

Control system

Automatic electronic pressure sensor controlling, recirculation function

Water quality monitor

TDS test pen+ on-line resistivity monitor

Electric requirements

AC110-220V,50/60Hz, 72W

Dimension and weight

Length×Width×Height:41×22×42cm / 12-14 kg

Standard configuration

Main body(including:1 set cartridge)+TDS pen+ accessory box
