Model
|
FH1000(X)
|
FH1200(X)
|
FH1500(X)
|
|
Exterior Size(W*D*H)
|
1000*800*2200mm
|
1200*800*2200mm
|
1500*800*2200mm
|
|
Internal Size(W*D*H)
|
800*750*745mm
|
1082*740*735mm
|
1380*750*745mm
|
|
Air Velocity
|
0.3~0.8 m/s
|
0.3~0.8 m/s
|
0.3~0.8 m/s
|
|
Noise
|
≤60dB
|
≤60dB
|
≤60dB
|
|
Fluorescent Lamp
|
15W*1
|
18W*1
|
36W*1
|
|
UV Lamp
|
30W*1
|
20W*2
|
30W*2
|
|
Glass Window
|
Toughened glass,5mm thickness, motor control
|
Toughened glass,5mm thickness, motor control
|
Toughened glass,5mm thickness, motor control
|
|
Material
|
Exterior body:Cold-roll steel sheets,coated with anti-bacteria powder
|
Exterior body:Cold-roll steel sheets,coated with anti-bacteria powder
|
Exterior body:Cold-roll steel sheets,coated with anti-bacteria powder
|
|
Side panel:glass,three sides visible
|
Side panel:glass,three sides visible
|
Side panel:glass,three sides visible
|
|
Work table:solid chemical-resistant physiochemical board
|
Work table:solid chemical-resistant physiochemical board
|
Work table:solid chemical-resistant physiochemical board
|
|
Base Stand
|
650mm
|
690mm
|
650mm
|
|
Power Supply
|
110~240V,50~60Hz(Optional)
|
110/220V,50/60Hz(Optional)
|
110~240V,50~60Hz(Optional)
|
|
Power Consumption
|
150W
|
150W
|
235W
|
|
Standard Accessory
|
1water tap,1gas tap,1water sink,base stand
|
1water tap,1gas tap,1water sink,base stand
|
1water tap,1gas tap,1water sink,base stand
|
|
2 waterproof socket:2*250W(max)
|
2 waterproof socket:2*250W(max)
|
2 waterproof socket:2*250W(max)
|
|
Active Carbon Filter
|
HEPA Filter
|
HEPA Filter
|
|
Exhaust duct(4m),HEPA filter,foot switch
|
Exhaust duct(4m),HEPA filter,foot switch
|
Exhaust duct(4m),HEPA filter,foot switch
|
|
Optional Accessory
|
Infrared sterilizer
|
Infrared sterilizer
|
infrared sterilizer
|
|
Net Weight
|
200kg
|
260kg
|
280kg
|
|
Gross Weight
|
230kg
|
320kg
|
370kg
|
|
Package Size
|
1080*1050*1500mm
|
1280*1050*1500mm
|
1580*1050*1500mm
|
