Heating mantle,98-II-C
Uses：
It applies to colleges, petrochemical industries, medicine, and environment protection institutions for liquid heating.
Characteristics：
1.Cold rolling sheet stretching and spraying exterior.
2.Auto temperature control; digital display; with characteristics of large heating area, fast warm-up, high temperature evenness, accurate tem-control, time and cost saving.
3.Featured by anti-corrosion, age-resistant, durable and safe.
4.Beautifully shaped, easy to operate and effective.
5.Adjustable test-tube rack.
MAIN TECHNICAL PARAMETERS：
|
Model
|
98-II-C
|
|
Capacity
|
50
|
100
|
250
|
500
|
1000
|
2000
|
|
(ml)
|
|
Voltage(V)
|
220V/50Hz
|
|
Max use temp(℃)
|
0-380
|
|
|
|
|
|
|
Power(w)
|
80
|
100
|
150
|
250
|
350
|
450
|
|
Working time
|
continuous
|
|
Exterior size(mm)
|
φ200×160
|
φ260×200
|
φ300×230
|
|
Packing size(mm)
|
230×230×170
|
290×290×220
|
330×330×250
|
|
N.W.(kg)
|
2.5
|
5.5
|
6.5
|
|
G.W.(kg)
|
2.8
|
6
|
7
|
|
Model
|
98-II-C
|
|
Capacity
|
3000
|
4000
|
5000
|
6000
|
10000
|
20000
|
|
(ml)
|
|
Voltage(V)
|
220V/50Hz
|
|
Max use temp(℃)
|
0-380
|
|
Power(w)
|
600
|
700
|
800
|
900
|
1200
|
2400
|
|
Working time
|
continuous
|
|
Exterior size(mm)
|
φ300×250
|
φ310×250
|
φ350×270
|
φ350×270
|
φ420×320
|
450×450×380
|
|
Packing size(mm)
|
330×330×270
|
330×330×270
|
380×380×290
|
380×380×290
|
450×450×340
|
500×500×400
|
|
N.W.(kg)
|
7.5
|
7.5
|
8.5
|
8.5
|
9.8
|
21
|
|
